Arlows Verbinder ( männlich ) Blau Dash 8 ( 3/4 - 16 UNF )

6,49 €

incl. 19% VAT , plus (Paketversand)

From	Unit price
2	6,23 €*
5	6,04 €*
10	5,84 €*

Arlows Adapter ( male ) Blue AN-8 ( 3/4 - 16 UNF )

Connect compatible AN fittings.

AN size: AN-8
Material: Aluminium
Finish: Anodised
Colour: Blue
Thread: 3/4 - 16 UNF

Colour
size

Available now!
Delivery time: 1 - 2 Workdays (DE - int. shipments may differ)

Description

ARLOWS · ADAPTER

Arlows Adapter ( male ) Blue AN-8 ( 3/4 - 16 UNF )

Connect compatible AN fittings.
This anodised aluminium adapter provides a transition between compatible AN mating parts. Choose the connection configuration and shape to suit the existing fittings and intended line route.

This version: AN-8, Blue.

Key benefits

MATCHING CONNECTIONS

The connection configuration identifies the male or female mating fittings required.

PLAN THE LINE ROUTE

The shape and connection direction help you route the line without unnecessary strain.

ALUMINIUM

The aluminium component supports a weight-conscious plumbing layout.

Technical specifications

Manufacturer	Arlows
SKU	AR1612-1
AN size	AN-8
Component	Adapter
Material	Aluminium
Finish	Anodised
Colour	Blue
Thread	3/4 - 16 UNF
Connections	2× male

Applications

For custom oil or fuel lines where every component is suitable for the fluid, pressure and temperature. Select by connection geometry and available clearance.

Installation & notes

Check both connections and sealing faces before installation. Start threads by hand, hold the mating part while tightening and route the lines without tension or twisting. AN flare connections seal at the matching sealing face rather than with thread tape. Follow the tightening instructions for the components used and leak-test the completed assembly before operation.

Permitted operating conditions depend on the ratings of every component in the assembly.
