ALU AN 90° AR8373
Arlows Aluminium AN Dash Fitting 90°
Right angle out. Less hose kink.
Anodized aluminium fitting with a 90° body for classic steel braided hose. Black or blue, Dash 4 to Dash 20. For fuel, oil, cooling and hydraulics when the line has to turn a corner. For PTFE hose use PTFE fittings. For less height pick the 90° block angle.
90° ANGLE
Full turn at the joint. The hose does not have to make the 90° itself.
ANODIZED ALU
Light, corrosion resistant, race look. Pick colour above: black or blue.
AN DASH
Fits common steel flex. Pick size above, threads in the table.
TIGHT BAY
At the block, cooler and frame, where the line must leave at a right angle.
Use cases
- Fuel and oil: rail, oil cooler, filter, catch can
- Cooling and hydraulics: stubs that leave the part at 90°
- Car, van, motorsport: a clean corner without hose pinch at the fitting
Technical data
| Dash | Thread | ID | OD |
|---|---|---|---|
| Dash 4 | 7/16-20 UNF | 5.56 mm | 11.13 mm |
| Dash 6 | 9/16-18 UNF | 8.73 mm | 13.89 mm |
| Dash 8 | 3/4-16 UNF | 11.12 mm | 16.28 mm |
| Dash 10 | 7/8-14 UNF | 14.27 mm | 20.24 mm |
| Dash 12 | 1 1/16-12 UNF | 17.47 mm | 23.82 mm |
| Dash 16 | 1 5/16-12 UNF | 22.20 mm | 30.50 mm |
| Dash 20 | 1 5/8-12 UNF | 28.50 mm | 35.81 mm |
- Part number: AR8373
- Material: aluminium, anodized
- Colours: black, blue
- Angle: 90°
- Hose: classic steel flex AR8394, not PTFE core
Fitment
Cut the hose square, assemble the fitting per the instructions. Dash size must match hose and counterpart. For PTFE Teflon hose (AR9106 / AR9107) use PTFE fittings. Straight, 30°, 45°, 180° and 90° block angle are separate items.
