Description
Arlows PTFE Braided Hose Set Dash 8 blue, 1 m, 90 degree and straight. PTFE braided hose and PTFE aluminium fittings in one size, for self-assembly. Do not mix with standard AN fittings, push-on fittings or the nylon-covered PTFE hose.
Your advantages at a glance
- Matched PTFE set instead of separate parts - Dash 8 throughout
- PTFE braided hose with PTFE aluminium fittings in blue
- 1 metre of hose, packed as one set
- The 90-degree end turns the line around a corner, the straight end sits on the port.
- Not for push-on hose and not for standard braided hose
Scope of delivery
- 1x AR7410-1 - Arlows 1 Meter PTFE / Teflon Stahlflexschlauch Dash 8 (3/4 - 16 UNF)
- 1x AR7339-1 - Arlows PTFE Alu Fitting Blau Dash 8 gerade
- 1x AR7351-1 - Arlows PTFE Alu Fitting Blau Dash 8 90 Grad
Technical data
- System: PTFE / Teflon braid
- Dash: Dash 8
- Port thread: 3/4-16 UNF
- Fitting colour: Blue
- Angle: 90 degree and straight
- Hose length: 1 metre
- Nominal inner diameter: 11.12 mm
- Fitting material: aluminium, anodized, PTFE type
- Hose: PTFE braided hose
- Supply condition: set, self-assembly
Assembly
The set is supplied unassembled. Hose and fittings are the PTFE version of the same Dash size. Colour refers to the fittings. A spare olive is not included.
Not included
- Spare olive, adapters, clamps
- Push-on fitting or standard aluminium Dash fitting
- Nylon-covered PTFE hose
- Extra angles or a second hose length
| Item number: | AR12935 |
