ALU AN 135° AR8375
Arlows Aluminium AN Dash Fitting 135°
More than 90°. Less than 180°.
Anodized aluminium fitting with a 135° body for classic steel braided hose. Black or blue. When 90° does not fold enough and 180° sends the line back on itself. For fuel, oil, cooling and hydraulics. For PTFE hose use PTFE fittings.
135° ANGLE
A strong turn. The line comes back at an angle without a full reverse.
ANODIZED ALU
Light, corrosion resistant, race look. Pick colour above: black or blue.
AN DASH
Fits common steel flex. Pick size above, threads in the table.
TIGHT BAY
At the block, turbo and frame, where 90° is not enough and the hose must not kink.
Use cases
- Fuel and oil: rail, oil cooler, filter, when the line almost has to run back
- Cooling and hydraulics: stubs with a sharp exit
- Car, van, motorsport: clean routing without hose pinch at the fitting
Technical data
| Dash | Thread | ID | OD |
|---|---|---|---|
| Dash 4 | 7/16-20 UNF | 5.56 mm | 11.13 mm |
| Dash 6 | 9/16-18 UNF | 8.73 mm | 13.89 mm |
| Dash 8 | 3/4-16 UNF | 11.12 mm | 16.28 mm |
| Dash 10 | 7/8-14 UNF | 14.27 mm | 20.24 mm |
| Dash 12 | 1 1/16-12 UNF | 17.47 mm | 23.82 mm |
| Dash 16 | 1 5/16-12 UNF | 22.20 mm | 30.50 mm |
| Dash 20 | 1 5/8-12 UNF | 28.50 mm | 35.81 mm |
- Part number: AR8375
- Material: aluminium, anodized
- Colours: black, blue
- Angle: 135°
- Hose: classic steel flex AR8394, not PTFE core
Fitment
Cut the hose square, assemble the fitting per the instructions. Dash size must match hose and counterpart. For PTFE Teflon hose (AR9106 / AR9107) use PTFE fittings. 90°, 180° and block angles are separate items.
