Description
Competition Intercooler Kit EVO1 for Audi RS3 8V / 8Y and TTRS 8S
Audi RS3 8V Sportback 270KW/367PS 04/2015-04/2016
Audi RS3 8V Sportback/Sedan 294KW/400PS 08/2017+
Audi RS3 8Y Sportback/Sedan 294KW/400PS 2021+
Audi TTRS 8S 294KW/400PS 11/2016+
Audi RSQ3 F3 294KW/400PS 10/2019+
The Competition high-performance intercooler has the following net dimensions (660x180x110 = 13,070cm³), offering a 14% larger flow area, as well as 57% more charge air volume compared to the original intercooler. The Competition high performance mesh is a high quality Tube Fin mesh with internal turbulators. Despite its size, the total weight of the intercooler is only 8.3kg. The end boxes of the intercooler are made of cast aluminum and have been optimized using flow analysis in the CFD system. The result is excellent cooling properties with the lowest backpressure. In addition, all our charge air coolers have an anti-corrosion coating with heat conduction properties. This guarantees long-lasting and optimal cooling with a significant increase in performance. Complete ready-to-install kit, simply replace with stock intercooler - plug and play. Tested and pressure stable up to 6 bar. All our products are subject to constant qualitative monitoring. Suitable for racing.
Dimensions original intercooler:
640mm x 163mm x 80mm
V=8,3 liters
A=1043 cm²
Dimensions WAGNERTUNING intercooler:
660mm x 180mm x 110mm
V=13,07 Liter
A=1188 cm²
Scope of delivery:
1 intercooler (black coated)
1 assembly instruction
| Item number: | AR12292 |
