Description
Arlows PTFE Nylon Braided Hose Set Dash 4 blue, 1 m, 2x straight. PTFE nylon-covered braided hose and PTFE aluminium fittings in one size, for self-assembly. Do not combine with standard AN fittings or push-on fittings.
Your advantages at a glance
- Matched PTFE set instead of separate parts - Dash 4 throughout
- PTFE hose with nylon braid and PTFE aluminium fittings in blue
- 1 metre of hose, packed as one set
- Straight ends for a direct connection.
- Not for push-on hose and not for standard braided hose
Scope of delivery
- 1x AR7414-1 - Arlows 1 Meter PTFE / Teflon Nylonstahflexschlauch Dash 4 (7/16 - 20 UNF)
- 1x AR7337-1 - Arlows PTFE Alu Fitting Blau Dash 4 gerade
- 1x AR7337-1 - Arlows PTFE Alu Fitting Blau Dash 4 gerade
Technical data
- System: PTFE / Teflon, nylon braid
- Dash: Dash 4
- Port thread: 7/16-20 UNF
- Fitting colour: Blue
- Angle: 2x straight
- Hose length: 1 metre
- Nominal inner diameter: 5.56 mm
- Fitting material: aluminium, anodized, PTFE type
- Hose: PTFE nylon braided hose
- Supply condition: set, self-assembly
Assembly
The set is supplied unassembled. Hose and fittings are the PTFE version of the same Dash size. Colour refers to the fittings. A spare olive is not included.
Not included
- Spare olive, adapters, clamps
- Push-on fitting or standard aluminium Dash fitting
- Extra angles or a second hose length
| Item number: | AR12902 |
