Description
Arlows PTFE Nylon Braided Hose Set Dash 3 blue, 1 m, 90 degree and straight. PTFE nylon-covered braided hose and PTFE aluminium fittings in one size, for self-assembly. Do not combine with standard AN fittings or push-on fittings.
Your advantages at a glance
- Matched PTFE set instead of separate parts - Dash 3 throughout
- PTFE hose with nylon braid and PTFE aluminium fittings in blue
- 1 metre of hose, packed as one set
- The 90-degree end turns the line around a corner, the straight end sits on the port.
- Not for push-on hose and not for standard braided hose
Scope of delivery
- 1x AR7413-1 - Arlows 1 Meter PTFE / Teflon Nylonstahflexschlauch Dash 3 (3/8 - 24 UNF)
- 1x AR7336-1 - Arlows PTFE Alu Fitting Blau Dash 3 gerade
- 1x AR7348-1 - Arlows PTFE Alu Fitting Blau Dash 3 90 Grad
Technical data
- System: PTFE / Teflon, nylon braid
- Dash: Dash 3
- Port thread: 3/8-24 UNF
- Fitting colour: Blue
- Angle: 90 degree and straight
- Hose length: 1 metre
- Nominal inner diameter: 3.18 mm
- Fitting material: aluminium, anodized, PTFE type
- Hose: PTFE nylon braided hose
- Supply condition: set, self-assembly
Assembly
The set is supplied unassembled. Hose and fittings are the PTFE version of the same Dash size. Colour refers to the fittings. A spare olive is not included.
Not included
- Spare olive, adapters, clamps
- Push-on fitting or standard aluminium Dash fitting
- Extra angles or a second hose length
| Item number: | AR12899 |
