Description
ARLOWS · AR2679
Arlows Ø 10 mm Aluminium banjo fitting to 2x Dash 6
Two AN connections on one banjo fitting.
This twin aluminium banjo provides two AN connections at a compatible hollow-bolt assembly, allowing two line routes to meet at one banjo fitting. This version: Bore: 10 mm. Connection thread: 2x Dash 6 UNF thread.
Benefits at a glance
TWO AN CONNECTIONS
The twin design connects two suitable lines to the same banjo fitting.
MATCHING BANJO BOLT
The stated bore helps you select the required bolt diameter.
Technical specifications
| Bore | 10 mm |
|---|---|
| Material | Aluminium |
| Colour | Blue anodised |
| Connection thread | 2x Dash 6 UNF thread |
| SKU | AR2679 |
Applications
For custom line branches with a suitable banjo port. Match the bolt, required flow and both lines as a complete assembly.
Installation & notes
Select a compatible hollow bolt and suitable sealing washers. Align the banjo without strain and assemble with the required seals. Check engagement length and fluid passages. Connect the AN mating fitting at its matching sealing face and leak-test the complete assembly.
Common question
Does it automatically increase flow?
No. Available flow depends on the bolt, line cross-sections and the complete system, among other factors.
